MYD Nomex(Comex) High Temperature Filter -- LF500
MYD Nomex high temperature filter with Dupont tag is bulit with 100% Dupont Nomex fibre, which has excellent high temperature endurance, continues 204 Celsius, peak 240 Celsius.
a. Limit oxygen index (LOI) 29%.
b. Not decompse or carbonize until 400 Celsius, non self-ignite or melt.
c. Excellent size stability in operating temperature, dry shrinkage less than 1%.
d. Excellent performance of anti chemical corrode, safe in low consistency acid & alkali and most of hydrocarbon.
e. Excellent performance of enduring grind, Nomex filter has the same ability with polyester and nylon to endure attrition and fatigue in normal temperature (a little better than acrylic fibre), but Nomex has a good double abilities of these performances when over 120 Celsius.
f. Its work will effected by hydrated situation in higher temperature.
MYD Conex high temperature filter is bulit with 100% Japan Teijin Conex fibre, has almost the same in physical and chemical performance to Nomex with its excellent anti chemical corrode, oxidation resist and high temperature endurance, continuous operating temperature 204 Celsius, peak 240 Celsius.
美达斯环保工业有限公司
过滤针刺毡技术参数 Technical Data of Needle Felt Filtration
品名(Product code) | LF500 |
成分(Component) | 针刺毡(Needle Punched filtration felt):100%Nomex 基布(Scrim):100%Nomex |
克重(Weight)(g/㎡) | 500±25 |
厚度(Thickness)(mm) | 2.0±0.2 |
断裂强度(Breaking strength) (样品Sample size 20cm×5cm) | 纵向(Warp): ≥700N 横向(Weft): ≥1000N |
断裂伸长(Elongation)(%) | 纵向(Warp): ≤35 横向(Weft): ≤55 |
透气量(Air permeability)(L/㎡.S) | 150~250 |
热收缩率(Dry shrinkage)(250℃) | < 1% |
使用温度(Operating temperature) | 连续(continuous): 204℃ 瞬间(Instant):250℃ |
表面处理(Surface Finished) | 热定型、烧毛、压光 (Heat set, singed, calendered) |
MYD Conex high temperature filter is bulit with 100% Japan Teijin Conex fibre, has almost the same in physical and chemical performance to Nomex with its excellent anti chemical corrode, oxidation resist and high temperature endurance, continuous operating temperature 204 Celsius, peak 240 Celsius.
厦门美达斯环保工业有限公司
过滤针刺毡技术参数 Technical Data of Needle Felt Filtration
品名(Product code) | LF500 |
成分(Component) | 针刺毡(Needle Punched filtration felt):100%Conex 基布(Scrim):100%Conex |
克重(Weight)(g/㎡) | 500±25 |
厚度(Thickness)(mm) | 2.0±0.2 |
断裂强度(Breaking strength) (样品Sample size 20cm×5cm) | 纵向(Warp): ≥700N 横向(Weft): ≥1000N |
断裂伸长(Elongation)(%) | 纵向(Warp): ≤35 横向(Weft): ≤55 |
透气量(Air permeability)(L/㎡.S) | 150~250 |
热收缩率(Dry shrinkage)(250℃) | < 1% |
使用温度(Operating temperature) | 连续(continuous): 204℃ 瞬间(Instant):250℃ |
表面处理(Surface Finished) | 热定型、烧毛、压光 (Heat set, singed, calendered) |
